ANTAKIPRO LED WALL WASHER 24 3W RGB

SPECIFICATIONS || AC100-240V 50/60Hz || 90W power consumption || LED source: 24*3W RGB 3in1 LEDs || 25° beam angle (30°/45°optional) || 0-100% smooth linear LED dimming || Auto run, DMX 512, Maser/Slave, Sound Active || IP65 3-Pin XLR cables IN/OUT || N.W.: 3KGS || G.W.: 4KGS || MEAS: 107X12X15CM || KEYS INSTRUCTION || Menu | UP | DOWN | ENTER || This light is ideal for professional stage, studio, and theatre applications ||

DMX MODE || 3 Channels Mode || Channel Function Instruction || CH1 R Dimmer Dimmer- Dark to Bright || CH2 G Dimmer Dimmer- Dark to Bright || CH3 B Dimmer Dimmer- Dark to Bright ||

8 Channels Mode || Channel Function Instruction || CH1 Total Dimmer : RGB Total Dimmer- Dark to Bright || CH2 R Dimmer : Red Dimmer- Dark to Bright || CH3 G Dimmer : Green Dimmer- Dark to Bright || CH4 B Dimmer : Blue Dimmer- Dark to Bright || CH5 Total Strobe : RGB Total Flash Strobe- Slowto Fast ||

CH6 Function Choice || 0~50 : CH1-CH5 Control. | 51~100 : Different Colors output | 101~150 : Colors Jump Change. | 151~200 : Colors Gradate. | 201~250 : Colors Pulse Change. | 251~255 : Sound-Active || CH7 Function/Speed : Slow to Fast (At the Colors output and sound choose the color) ||

DIGITAL SHOW FUNCTION FORM || d001 : DMX address : 001~512 || A001 : DMX address : 001~512 || r255 : Red dim : 000~255 || G255 : Green dim : 000~255 || b255 : Blue dim : 000~255 || FH99 : Strobe : 01 ~ 99 || CL01 : Colors choose : 01 ~ 08 || CC99 : Colors Jump : 01 ~ 99 || DE99 : Colors Gradate : 01 ~ 99 || CP99 : Colors Pulse : 01 ~ 99 || SU01 : Colors : 01~09
